Features
- SmartHeat® Technology: Automatically melts snow and ice to maintain visibility.
- Multifunctional Design: Includes stop, tail, turn, reverse, front position, and side marker light options.
- Flexible Mounting: Compatible with flange, grommet, and L-shaped bracket mounts.
- Energy Efficient: Long-lasting LEDs reduce power consumption compared to traditional bulbs.
- Sealed to IP69K: Protects against water, dust, and high-pressure washing.
- DOT-Compliant: Legal for on-road use, meeting FMVSS 108 standards.
- Optional Features: Flash and strobe functionality available.
Street Legal & Easy Installation
The Model 274 is fully DOT-approved and meets FMVSS 108 standards, making it legally compliant for on-road use. Designed for hassle-free installation, this signal light retrofits standard 6” oval lights and offers multiple mounting options, including flange, grommet, and L-shaped brackets. The heating function is activated through a simple wiring connection, ensuring straightforward integration into your vehicle’s electrical system.
Specifications
| Description | 12-24V DOT LED Heated Red Stop, Tail & Turn Light |
| Height | 57.00 mm / 2.24 in |
| Width | 165.50 mm / 6.52 in |
| Depth | 21.00 mm / 0.83 in |
| Shape | Oval |
| Outer Lens Material | Polycarbonate |
| Outer Lens Color | Clear |
| Housing Material | Polycarbonate |
| Housing Color | Black |
| Bezel Color | Red |
| Mounting Type | Grommet/Flange Bracket |
| Retrofits | Standard 2″ x 6″ Signal Lights |
| Minimum Operating Temperature | -40 °C / -40 °F |
| Maximum Operating Temperature | 50 °C / 122 °F |
| Mating Connector | 3-Pin AMP Connector (282087-1) |
| Product Weight | 0.35 lbs / 0.16 kgs |
| Shipping Weight | 1.35 lbs / 0.61 kgs |
Frequently Asked Questions
SmartHeat® automatically melts ice and snow, preserving light output and visibility in freezing or snowy conditions.
Yes. It is DOT compliant and meets FMVSS 108 standards, making it legal for highway use.
Tail, stop, turn, reverse, fog, and side marker functions, all in one sealed 2″×6″ unit.
Compatible with flange, grommet, and L-shaped bracket mounts for flexible installation.
