Applications
The Model 420070 Blackout Driving Light is an essential lighting component for a wide range of military vehicles, including tactical trucks, armored personnel carriers, and reconnaissance units. Its green blackout light is purpose-built for night operations where maintaining a low visual profile is critical. Whether used during convoy movements, perimeter patrols, or silent approach missions, this light ensures safe vehicle navigation without compromising stealth.
Its compatibility with diverse mounting systems and electrical configurations makes it a versatile solution for both new vehicle builds and retrofit programs in defense fleets worldwide.
Features
The blackout front driving and signal lights feature a compact all-in-one design combining low-visibility driving illumination with left and right amber turn signals. Constructed with a rugged aluminium housing and polycarbonate lens, they are sealed to IP67 for dust and water resistance. Designed to operate in 12–24 V systems, these lights offer optional infrared output for NVG compatibility, and use reliable Deutsch DT-series connectors for secure installation.
Certified to MIL‑STD standards, they provide dependable performance in tactical, off-road, and mission-critical applications.
| Input Voltage | 12 – 24 V DC |
| Power Consumption | 4.1 W @ 12V, 4.5 W @ 24V |
| Outer Lens Material | Polycarbonate |
| Outer Lens Colour | Clear |
| Housing Material | Aluminum |
| Housing Colour Options | 13 Military Standard RAL options |
| Mounting Type | Pedestal Mount |
| Operating Temperature | -40 °C to 85 °C |
| Weight | 0.6 kg |
| Ingress Protection | IP68 |
| Connector Options | 5 variants including AMP & MS27142 |
| Standards | MIL-STD-810F, MIL-STD-461F, STANAG 4381 |
Frequently Asked Questions
NVG-compatible lights operate in infrared wavelengths, which are invisible to humans but clearly visible through night vision gear.
Use the standard LED driving and indicator mode. Blackout mode is not for public road use.
Yes, they meet IP67 and MIL‑STD 810F standards for durability and harsh environment performance.
Custom connector options are available.
