Features
- Compact Design: Packs the power of larger models into a smaller 4″ x 4″ form factor.
- Rugged Construction: Features a die-cast aluminum housing and UV-resistant polycarbonate lens.
- Multiple Beam Patterns: Available in different beam configurations for varied applications.
- 24V Version for Theft Deterrence: Offers an added layer of security in sensitive environments.
- Weatherproof: Integrated 2-pin Deutsch weatherproof socket ensures reliable connections.
Versatile Mounting & Application
The compact yet powerful design of this LED auxiliary light makes it suitable for multiple mounting positions on trucks, construction equipment, agricultural machinery, and emergency vehicles. Its universal mounting options allow for flexible placement to suit a wide range of lighting needs.
What is an Auxiliary Light?
An auxiliary light is a secondary or additional light source designed to enhance visibility and improve illumination beyond standard vehicle lighting. Unlike primary headlights or work lights, auxiliary lights serve specific functions, such as spotlighting, floodlighting, or providing additional directional lighting in low-visibility conditions.
They are commonly used in off-road vehicles, construction equipment, agricultural machinery, and emergency response vehicles to ensure better visibility and safety. Whether mounted on a vehicle, heavy equipment, or a stationary work site, auxiliary lights help users adapt to challenging environments, extend operational hours, and enhance overall lighting performance where standard lights may not be sufficient.
Specifications
| Description | 12 – 24V Auxiliary Light with Trapezoid Beam Pattern |
| Light Output (Raw) | 3,900 Lumens |
| Light Output (Effective) | 2,500 Lumens |
| Color Temperature | 5700K |
| Current Draw | 1.6A @ 24V |
| Housing Material | Die-Cast Aluminum |
| Lens Material | UV-Resistant Polycarbonate |
| Lens Color | Clear |
| Housing Color | Black |
| Mounting Type | Universal Pedestal Mount |
| Operating Temperature | -40 °C to 65 °C |
| Connector | Integrated 2-Pin Deutsch Weatherproof Socket (DT04-2P) |
| Standards | IP56 |
Part numbers
| 832-001 | Trapezoid Beam | Standard |
| 832-002 | Spot Beam | Heavy-Duty XL Series |
