Benefits
-
Dual-mode output: switch between visible and IR
-
Low-profile housing minimizes drag and signature
-
Hermetically sealed for all-weather, high-altitude performance
-
Compliant with key military and aviation lighting standards
-
Ideal for retrofit or new airframe integration
Application
Model 500080 is built for close-formation flight operations where visibility to fellow pilots and stealth to adversaries is crucial. The dual-mode LED allows for tactical flexibility, switching between visible and IR illumination for coordinated formation flying in both overt and covert missions.
Its rugged, hermetically sealed design ensures consistent performance across all altitudes, weather conditions, and combat zones.
Specifications
| Light Source | LED |
| Dual Mode | Visual + Infrared (IR) |
| Power Supply | 28 VDC |
| Power Consumption | 3W |
| MTBF | > 20,000 flight hours |
| Operating Temperature | -55 °C to +80 °C |
| Compliance | RTCA DO-160G MIL-STD-810G MIL-STD-461F MIL-STD-3009 |
| Socket Type | D38999/20JA35PN or D38999/21YA35PN (Hermetic) |
| Dimensions | 144 mm x 51 mm x 37.5 mm |
| Mounting | Panel mount with 4x Ø4.2 mm holes (131 mm spacing) |
