Features
- Dual Burn® High Beam Optics: Provides an extra burst of light.
- Plug-and-Play Installation: Simple setup for 7″ LED headlights.
- ECE Compliant: Suitable for on-road use.
- Bezel Options: Available in black or chrome.
- ComfortLite® High Beams: Optimized for comfort during high-beam usage.
Effective Lumen Isolux Charts
Applications
- Automotive
- Railroad
- Agriculture
- Construction
- Industrial
- Motorcycle
- Off-Road 4×4
- Powersports
- Specialty Vehicles
- Truck & Bus
Specifications
| Model | 8700 EVO 2 PRO WIthout DRL |
| Compliance | ECE Compliant drop-in replacement for 7″ round headlights |
| Lumen Output | Raw: 3,200 (High), 1,770 (Low); Effective: 1,260 (High), 750 (Low) |
| Candela Output | High beam: 54,000; Low beam: 35,003 |
| Input Voltage | 12V – 24 V DC |
| Current Draw | 3.50A @ 12V DC (High Beam) |
| Lens Material | Polycarbonate |
| Housing Material | Aluminum |
| Mounting Type | 2D1 “PAR56” or 7” round headlights |
| Connector | H4 |
| Wiring | Black: Ground, Yellow: Low Beam, White: High Beam, Red: Park (Front Position) |
| Standards | Sealed to IP 67, ECE Reg. 7, 10, 87, & 112 |
Part Numbers
| Color | Description | Part Number |
|---|---|---|
| Green | Green Bucket | 0561382 |
| Tan | Tan Bucket | 0561392 |
| Black | Black Bucket | 0561342 |
Note:
Part number 0547932 (CARC Green lamp) is mechanically and electrically interchangeable with 0561382 (Green Bucket).
