Key Features
- Reliable performance in all environmental conditions.
- Betalight® luminance preserves night vision.
- Limited 140° viewing angle for enhanced security.
- Color options for functional differentiation.
- No power source or maintenance required.
- Lightweight, portable, and easy to deploy.
- Long operational life, with continuous illumination for 10 years.
- NATO Stock Number: Defile 6210-99-209-4968.
Typical Applications
Route and Defile Markers emit 400 microlamberts (µL) of light, providing visibility in starlight conditions up to 100 meters. The light source is recessed to limit the viewing angle to 140°, ensuring directional visibility while enhancing security. The markers maintain brightness in varying environmental conditions, unaffected by temperature, humidity, altitude, or vibration.
These markers are ideal for:
- Minefield marking: Defining the perimeter and safe lanes through a minefield.
- Bridge marking: Indicating bridge dimensions, visible even on low-profile bridges when elevated.
- Route marking: Clear route indication via attachment to poles, trees, or wires.
- Route designation: Assigning specific route functions through color configurations.
Specifications
| Illumination | 400 microlamberts (µL) |
| Viewing Angle | 140° (2500 mrads) |
| Visibility Range | 100 meters in starlight conditions |
| Light Source | Betalights® (gaseous tritium light source) |
| Operational Life | 10 years |
| Power Requirement | None (self-luminous) |
| Operating Temperature | -60°C to +70°C |
| Body Material | Polycarbonate |
| Arrow Material | Polycarbonate |
| Bracket Material | Zinc-plated steel with Crodalux polyester coating |
| Length | 130 mm |
| Width | 72 mm |
| Depth | 27 mm |
| Weight | 170 g |
| Colour Options | Blue, red, orange, green, yellow, white |
| Mounting | Rotating bracket for poles and structures |
| Fixing Bracket | Zinc-plated steel with Crodalux polyester powder |
| Environmental Resistance | Operational in hazardous atmospheres, water immersion |
| Applications | Minefield marking, bridge marking, route marking, route designation |
| Standards Compliance | ISO 9001, UK Ministry of Defence Standard 62/4 |
| NATO Stock Number | Defile 6210-99-209-4968 |
