Landing lights

Landing Lights



A range of landing lights that are integral to the landing sequence of a huge range of aircraft used for commercial and military purposes. The range includes LED Bulb Replacements such as the PAR 64 Bulb, the High Intensity LED Landing Light and a Dual Mode Landing Light.

Par 64 Bulb

An incredibly efficient product, the PMA approved PAR 64 LED Bulb Replacement is used in both commercial and military applications. It promises a long operational lifespan with an MTBF of 23,000 hours and a 5 year warranty. The light delivers through life costs savings through reduced maintenance cycles and helps airlines to deliver improved dispatch rates.

One of the best features of the PAR 64 is that the bulbs do not need to be replaced, as the use of LEDs are employed to ensure functionality and efficiency. This use of LEDs also means that the bulb has reduced power consumption compared to a traditional bulb.

PAR 64 LED Replacement Landing Light
Key features
  • Peak intensity 600,000 cd
  • Input voltage 28V AC/28V DC
  • Power consumption 162W AC/132W DC
  • Operating temperature: -54°C to +71°C
  • Storage temperature -54°C to +85°C
  • Mean Time Between Failure in excess of 23,000 hours
  • Weight: 938g
  • Aviation White 6000K typ
  • Aluminium housing, matt black anodised finish
  • Hard coated polycarbonate lens
  • Output: 12 degrees full width to 10% max
  • Qualified to
             Environmental: MIL-STD 810G
             EMC:                MIL-STD 461F
                                      RTCA-DO 160G
             Power input:     MIL-STD 704A
                                      RTCA-DO 160G
Benefits
  • High through life cost savings over existing technology
  • Replacement unit fully meets Q4559X and Q4559
  • Excellent resistance to shock and vibration
  • No future requirement to replace bulbs
  • Utilises existing housing and transformers
  • 5 year warranty
  • Repairable unit
  • Reduced power consumption
  • Doesn’t suffer degradation over time

Significantly reduced operating costs for commercial aircraft operators who use halogen based sealed beam landing lights and need increased operational lifetime and improved dispatch rates. The PMA approved PAR 64 LED replacement landing light offers a saving of $1,000 per aircraft per annum over sealed beam halogen units through reduced power consumption, a 100 fold increase in operational life and reduced maintenance cycles.

High Intensity LED Landing Light

This light is not only high in intensity but also high in reliability and efficiency. The High Intensity LED Landing Light offers a peak intensity of 400,000cd (cd refers to Candela, which is the unit of measurement for visible light) and has an MTBF of 27,000 hours.

The unit offers excellent resistance to shock and vibration. Like its counterparts, there is no requirement to replace the bulbs given the use of LEDs, which significantly reduces maintenance costs.

High Intensity LED Aircraft Landing Light

Dual Mode Landing Light - visible and covert modes

Dual Mode Landing Light

specifically designed for military applications is the Dual Mode Landing Light, named as such as it can switch between visible and covert modes from the cockpit. The visible and covert modes enable landing and taxiing both using full illumination or when flying on covert operations using Night Vision Goggles.

In addition, the unit offers an MTBF of over 13,000 hours and a peak intensity of 200,000cd making it an extremely reliable and effective product for use in the field. Complete with a toughened borofloat glass lens that offers excellent resistance to shock and vibration.

This High Intensity LED landing light is a robust dual mode solution with a peak intensity of 200,000 cd. The visible and covert modes enable landing and taxiing both using full illumination or when flying on covert operations using military night vision goggles.
The lighting fixture is designed as a replacement for existing PAR 46 units. The LED solution offers an MTBF in excess of 10,000 hours and far exceeds performance of existing technologies. The rugged light has a toughened borofloat glass lens with a matt black hard anodised finish to MIL-A-8625.
Key features
  • Visible and covert modes
  • Modes switched via a cockpit control
  • Overt peak intensity 200,000 cd
  • Covert peak intensity 100 W-sr
  • Input voltage 115V AC
  • Power consumption 145W
  • Weight: 1.4kg
  • Operating temperature: -46°C to +71°C
  • Storage temperature -55°C to +71°C
Key features
  • Overt colour – Aviation White 6000K typ
  • Covert wavelength 850 nm
  • Aluminium housing, matt black anodised finish
  • Environmental qualification to MIL-STD-810G
  • EMC qualification to MIL-STD-461F*
  • Overt output: 22° full width to 10% max
  • Covert output: 31° full width to 10% max
  • Mean Time Between Failure in excess of 10,000 hours
Benefits
  • Excellent resistance to shock and vibration
  • Dual mode capability controlled via the cockpit
  • No requirement to replace bulbs
  • High through life cost savings over existing technology
