EFL Series LED Area Lighting
The EFL series offers a high reliability rugged & durable area light, the low profile designis available in a range of size options. The EFL is designed to deliver power savings and improved MTBF over fluorescent tubes and the units can be used as part of an emergency lighting system. The EFL features external dimming control and is available with a secondary green, blue or red option.
The units are designed to be surface or recess mounted for hard shelter applications, or attached via webbing for tent and soft shelter use.
Key features
- High reliability
- Rugged, durable construction
- Dimmable
- Dual colour mode
- Sealed to IP56
- MTBF 50000 hours
- NVG Friendly
Key features
- ROHS compliant
- Designed to meet MIL-STD-461 & DEFSTAN 59-411
- Colour temperature 4500-6000K (warm white light versionalso available)
- Case touch temperature max 60°C (140°F)
- Operating temperature range -40°C to 50°C (-40°F to-122°F)
- Storage temperature range -40°C to 70°C (-40°F to -158°F)”
Technical Specifications
- Description
EFL Shelter light
Length
Shape
Outer Lens Material
Outer Lens Color
Housing Color
Min & max Operating
Temperature
Connector or Wiringlight
|
|
24 – 110 – 230V
EFL Shelter light
300 – 600 – 1200mm
Rectangular
Polycarbonate / acrylic blend
Diffused
Black or nature anodized
-35 °C
54 °C
Flying lead
